AmeriGlide Atlas Vertical Platform Lift - Commercial

spacer

Description

Commercial wheelchair lift requirements vary from state to state, and region to region. We can help you with the process of determining what your unique requirements are for your area. We provide lifts for churches, schools, playground areas, and even unique applications such as commercial pleasure boats. We have provided a wide variety of lifts including shaft enclosures and 3 stop applications. We work with builders as well as local authorities to ensure that the process of purchasing and installing a lift goes as smoothly as possible.

For Use Indoors or Outdoors

When you review the prices we show here in this section under options you should consider them as high estimate guidelines only as all commercial lifts are custom quotes. In California and several other states, for example, the standard commercial package must be further custom configured. Please call and allow us to provide you with a quotation for the lowest price obtainable anywhere.

These lifts can be configured to meet any requirements. They are built to ASME standards, and can be configured to comply with the A17.1 and A18.1 provisions of the ADA. In no case does a commercial grade lift automatically comply with local standards so you need to contact us, describe your application and location, and we will provide you with a quotation and instructions for how to proceed for approvals.

Product Specs
  • Lifting Capacity550 lb
  • Standard Lift Height96"
  • Maximum Lift Height144"
  • PortableNo
  • Arrives AssembledNo
  • Drive SystemDirect Worm-Gear & Screw-Nut
  • Optional Drive SystemsNone
  • Battery Powered OptionYes
  • Constant Pressure Platform ControlYes
  • Emergency Stop Platform ControlStandard
  • Alarm ButtonStandard
  • Keyed Platform ControlStandard
  • Call-Send ControlsOne Direction with Key x2
  • Optional Call-Send ControlsTwo Direction Toggle, Two Direction Toggle with Key
  • Platform TypeSolid
  • Platform Size34" x 54"
  • Optional Platform Sizes40" x 54"
  • Platform ConfigurationStraight-Thru Access
  • Optional Platform ConfigurationsAdjacent Access
  • Upper Landing GateOptional
  • Upper Access RampNone Available
  • Lower Access Ramp18" Fixed Toeplate
  • Grab RailOptional
  • Guard PanelStandard
  • Maximum Stops3
