Our extensive work with commercial applications has given us the knowledge to work with the AmeriGlide Atlas Tall Residential unit that has lifting heights that start at 72" and go up to 144". Although the Atlas is one of the best known lifts on the market, there are always special requirements when you work with such tall units. Please give us a call and let us put our experience to work for you AND offer you the lowest price you will get anywhere.
The Atlas Tall Residential comes standard with an expanded metal platform, folding entry ramp, and keyed platform controls. A wide variety of options are available meaning that we can build the exact lift that you need - keeping you safe and saving you money.
| Lifting Capacity | 550 lb |
| Standard Lift Height | 72" |
| Maximum Lift Height Upgrade | 144" |
| Portable | No |
| Arrives Assembled | No |
| Drive System | Direct Worm-Gear & Screw-Nut |
| Optional Drive Systems | None Available |
| Battery Powered Option | Yes |
| Constant Pressure Platform Control | Yes |
| Emergency Stop Platform Control | Included |
| Alarm Button | None Available |
| Keyed Platform Control | Included |
| Call-Send Controls | Optional Call-Send, Call-Send with Key, Toggle, Toggle with Key |
| Platform Type | Expanded Metal |
| Platform Size | 34" x 54" |
| Optional Platform Sizes | 40" x 54" |
| Platform Configuration | Straight-Thru Access |
| Optional Platform Configurations | Adjacent Access |
| Upper Landing Gate | Optional |
| Upper Access Ramp | None Available |
| Lower Access Ramp | Automatic Folding |
| Grab Rail | Included |
| Guard Panel | Optional |
| Maximum Stops | 3 |
-
Lifting Height
- 72" Maximum Lift Height: +$0.00
- 96" Maximum Lift Height: +$1,700.00
- 120" Maximum Lift Height: +$2,250.00
- 144" Maximum Lift Height: +$3,000.00
- 72" Maximum Lift Height: +$0.00
-
Tower Orientation
- Tower On The Left: +$0.00
- Tower On The Right: +$0.00
- Tower On The Left: +$0.00
-
Power Source
- AC Powered: +$0.00
- AC Powered with DC Battery Backup (Batteries Not Included): +$1,572.00
- AC Powered: +$0.00
-
Platform Size
- 34" x 54" Platform: +$0.00
- 40" x 54" Platform (For Adjacent Access Only): +$0.00
- 34" x 54" Platform: +$0.00
-
Platform Access
- Straight Through: +$0.00
- 90° Adjacent Access: +$228.58
- Same Side Entry / Exit (requires Solid End Wall): +$471.43
- Straight Through: +$0.00
-
Platform Gate
- No Platform Gate: +$0.00
- Platform Gate with Interlock: +$928.58
- No Platform Gate: +$0.00
-
Platform Controls
- Paddle Controls with Emergency Stop Button: +$0.00
- Paddle Controls with Emergency Stop Button: +$0.00
-
Platform Control Options
- Keylock for Platform Controls: +$0.00
- Backlit Emergency Stop Button: +$100.00
- Keylock for Platform Controls: +$0.00
-
Platform Options
- Automatic Ramp for Ground to Platform Transition: +$0.00
- Solid Hand Rail: +$185.72
- Solid End Wall: +$314.29
- Control Wall Extension: +$314.29
- Solid Platform: +$271.43
- Solid Platform with Safety Pan: +$485.72
- Inside Grab Bar - 48": +$107.15
- Automatic Ramp for Ground to Platform Transition: +$0.00
-
Landing Controls
- Pushbutton Call Control (each): +$135.00
- Keyed Pushbutton Call Control (each): +$232.50
- Toggle Call & Send Control (each): +$195.00
- Keyed Toggle Call & Send Control (each): +$285.00
- Pushbutton Call Control (each): +$135.00
-
Landing Gate
- No Landing Gate: +$0.00
- Left Swing Landing Gate - with Interlock & Keyed Pushbutton Call Control: +$1,185.72
- Right Swing Landing Gate - with Interlock & Keyed Pushbutton Call Control: +$1,185.72
- Left Swing Landing Gate - with Interlock & Keyed Toggle Call/Send Control: +$1,242.86
- Right Swing Landing Gate - with Interlock & Keyed Toggle Call/Send Control: +$1,242.86
- No Landing Gate: +$0.00
-
Landing Gate Options
- Oversized Upper Landing Gate Upcharge: +$378.58
- Oversized Upper Landing Gate Upcharge: +$378.58
-
Interlocks
- Additional Interlock (each): +$450.00
- Additional Interlock (each): +$450.00
-
Other Options
- 3 Stop Wiring Charge: +$450.00
- Batteries for Backup System: +$367.00
- 3 Stop Wiring Charge: +$450.00
-
Additional Delivery Services
- Trucking Terminal or Commercial Location with Loading Dock: +$0.00
- Liftgate Delivery, 28" & 52" Units Only: +$279.00
- Limited Access Delivery Charge: +$109.00
- AK, HI, PR, or International - Please Call for Quote: +$0.00
- Trucking Terminal or Commercial Location with Loading Dock: +$0.00
