Regular Price: $6,599.00
$4,459.00
Plus Shipping
The AmeriGlide Hercules II Commercial Vertical Platform Lift sets the standard for commercial lifts with a full range of features and low prices. It has a 600 pound weight capacity and comes in 4', 6', 8', 10', 12', or 14' lift heights. When configured to your specific application the Hercules II Commercial will meet ASME A18.1, Section 2 and CSA B44.1 / ASME 17.5 safety design standards.
| Lifting Capacity | 600 lb |
| Standard Lift Height | 53" |
| Maximum Lift Height Upgrade | 171" |
| Portable | No |
| Arrives Assembled | No |
| Drive System | 53" - 125" Acme Screw Drive, 149" - 171" Ball Screw Drive |
| Optional Drive Systems | None Available |
| Battery Powered Option | Yes |
| Constant Pressure Platform Control | Yes |
| Emergency Stop Platform Control | Included |
| Alarm Button | Optional Audible Alarm |
| Keyed Platform Control | Optional |
| Call-Send Controls | Optional Non-Keyed & Keyed Call-Send |
| Platform Type | Solid with Non-Skid Coating |
| Platform Size | 36" x 54" Platform (34" Usable Width) |
| Optional Platform Sizes | 36" x 60" (34" Usable Width), 42" x 54" (40" Usable Width) |
| Platform Configuration | Straight-Thru Access |
| Optional Platform Configurations | Same Side Entry-Exit, Adjacent Access |
| Upper Landing Gate | Optional |
| Upper Access Ramp | None Available |
| Lower Access Ramp | Fixed, Optional Automatic |
| Grab Rail | Included |
| Guard Panel | 42" |
| Maximum Stops | 3 |
| Lift Speed (FPM) | 10 |
-
Lifting Height
- 53" Max Lift Height, Acme Screw Drive: +$0.00
- 77" Max Lift Height, Acme Screw Drive: +$730.00
- 101" Max Lift Height, Acme Screw Drive: +$1,840.00
- 125" Max Lift Height, Acme Screw Drive: +$3,450.00
- 149" Max Lift Height, Ball Screw Drive: +$4,940.00
- 171" Max Lift Height, Ball Screw Drive: +$6,330.00
- 53" Max Lift Height, Acme Screw Drive: +$0.00
-
Crating & Assembly
- No Crating - Some assembly is required.: +$0.00
- 36" x 54" Platform: +$0.00
- 53" Unit Shipped Crated & Fully Assembled: +$462.00
- 36" x 60" or 42" x 54" Platform - Requires Extra Large Crate: +$0.00
- 53" Unit Shipped Crated & Fully Assembled: +$691.00
- No Crating - Some assembly is required.: +$0.00
-
Tower Orientation
- Tower On The Left: +$0.00
- Tower On The Right: +$0.00
- Tower On The Left: +$0.00
-
Power Source
- AC Powered: +$0.00
- DC Battery Powered - Battery provides 15-20 cycles during power outage. Batteries included.: +$999.00
- AC Powered: +$0.00
-
Electronics
- A commercial electronics control board allows operation with doors, gates, multiple call/send controls, and other devices.: +$0.00
- Commercial Electronics Control Board: +$0.00
- A commercial electronics control board allows operation with doors, gates, multiple call/send controls, and other devices.: +$0.00
-
Platform Type
- 36" x 54" Straight Thru (34" Usable Width): +$0.00
- 36" x 60" Straight Thru (34" Usable Width): +$246.00
- 42" x 54" Straight Thru (40" Usable Width): +$492.00
- 36" x 54" 90 Degree (34" Usable Width): +$369.00
- 36" x 60" 90 Degree (34" Usable Width): +$491.00
- 42" x 54" 90 Degree (40" Usable Width): +$738.00
- 36" x 54" Straight Thru (34" Usable Width): +$0.00
-
Platform Access
- Straight Thru or 90 Degree: +$0.00
- Same Side Entry & Exit - Lift height must be 101" or greater.: +$368.00
- Straight Thru or 90 Degree: +$0.00
-
Platform Gate
- Lifts 8' and over that are not in a hoistway require a platform gate or an interlock for a customer provided gate.: +$0.00
- No Platform Gate: +$0.00
- Left Swing 36" Wide Straight Thru Platform Gate with Interlock: +$614.00
- Right Swing 36" Wide Straight Thru Platform Gate with Interlock: +$614.00
- Left Swing 42" Wide Straight Thru Platform Gate with Interlock: +$862.00
- Right Swing 42" Wide Straight Thru Platform Gate with Interlock: +$862.00
- Left Swing 90 Degree Platform Gate with Interlock: +$984.00
- Right Swing 90 Degree Platform Gate with Interlock: +$984.00
- Lifts 8' and over that are not in a hoistway require a platform gate or an interlock for a customer provided gate.: +$0.00
-
Platform Controls
- Paddle Controls with Emergency Stop Button: +$0.00
- Paddle Controls with Emergency Stop Button: +$0.00
-
Platform Control Options
- Emergency Alarm & Lighted Button: +$208.00
- Keylocks for Controls: +$34.00
- Emergency Alarm & Lighted Button: +$208.00
-
Platform Options
- 42" High Side Walls: +$0.00
- Solid Platform with Safety Pan: +$0.00
- Inside Grab Bar: +$0.00
- 42" High Side Walls: +$0.00
-
Ramp Type & Pit Switch
- Fixed Ramp: +$0.00
- Automatic Ramp: +$0.00
- No Ramp with Pit Switch Option: +$122.00
- Fixed Ramp: +$0.00
-
Landing Controls
- Call/Send Control Station (each): +$119.00
- Wireless Call/Send Control Stations (pair): +$479.00
- Keylocks for Controls (each): +$34.00
- Call/Send Control Station (each): +$119.00
-
Landing Gate
- Landing gates below include an interlock and a call/send control built into the gate.: +$0.00
- Left Swing 36" Wide Landing Gate with Interlock & Call/Send Control (each): +$809.00
- Right Swing 36" Wide Landing Gate with Interlock & Call/Send Control (each): +$809.00
- Left Swing 42" Wide Landing Gate with Interlock & Call/Send Control (each): +$979.00
- Right Swing 42" Wide Landing Gate with Interlock & Call/Send Control (each): +$979.00
- Keylocks for Controls (each): +$34.00
- Landing gates below include an interlock only.: +$0.00
- Left Swing 36" Wide Landing Gate with Interlock Only (each): +$739.00
- Right Swing 36" Wide Landing Gate with Interlock Only (each): +$739.00
- Left Swing 42" Wide Landing Gate with Interlock Only (each): +$909.00
- Right Swing 42" Wide Landing Gate with Interlock Only (each): +$909.00
- Keylocks for Controls (each): +$34.00
- Landing gates below include an interlock and a call/send control built into the gate.: +$0.00
-
Fire Rated Doors
- No Door: +$0.00
- Fire-Rated Hoistway Door with EMI - Left (each): +$2,079.00
- Fire-Rated Hoistway Door with EMI - Right (each): +$2,079.00
- Fire-Rated Hoistway Door with Electric Strike - Left (each): +$2,219.00
- Fire-Rated Hoistway Door with Electric Strike - Right (each): +$2,219.00
- No Door: +$0.00
-
Interlocks
- Surface mount EMI interlocks below are for a customer provided door or gate.: +$0.00
- Left Swing Top Landing Door/Gate EMI Interlock (each): +$409.00
- Right Swing Top Landing Door/Gate EMI Interlock (each): +$409.00
- Flush mount electric strike interlocks below are for a customer provided door or gate.: +$0.00
- Top Landing Electric Strike Interlock - Metal Frame (each): +$409.00
- Bottom Landing Electric Strike Interlock - Metal Frame (each): +$409.00
- Top Landing Electric Strike Interlock - Wood Frame (each): +$409.00
- Bottom Landing Electric Strike Interlock - Wood Frame (each): +$409.00
- Other Interlock Options: +$0.00
- Keyed Dead Latch for Flush Mount Electric Strike Interlock (each): +$139.00
- Wiring For Interlock (per landing): +$159.00
- Surface mount EMI interlocks below are for a customer provided door or gate.: +$0.00
-
Accessories
- Anchor Bolt Kit: +$0.00
- Tower Braces: +$154.00
- 3rd Stop Wiring Charge: +$492.00
- Phone Jack: +$137.00
- Emergency Light: +$138.00
- Fascia Panel (per foot): +$59.00
- Automatic Door Opener - Requires Upgraded Electronics: +$2,349.00
- Anchor Bolt Kit: +$0.00
-
Additional Delivery Services
- Free Liftgate Service on 53" Units As Requested: +$0.00
- Free Liftgate Service on 53" Units As Requested: +$0.00
